Description

• Active HF distribution system with ceramic filtering
• For distributing signals from 2 antennas to 8 diversity receivers in order to minimise cable and antenna costs in wireless multi-channel systems
• Inputs: 2x 50 Ohm BNC sockets on the rear panel
• Outputs: 16x BNC sockets on the rear panel, 8 sockets per antenna
• Frequency range (A1B1): 470 bis 615 MHz
• Dimensions (W x H x D): 487 x 180 x 45 mm
• Weight: 1.45 kg
• Includes DCR15/A4U power supply
